Triplex | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|
Models | C mm |
H mm |
P Kg |
B mm |
A mm |
L mm |
E mm |
D mm |
Q Kg |
|
25 TBCH 2700 | 2700 | 1700 | 715 | 1350 | 2450 | 800 | 240÷1000 | 500 | 2500 | |
25 TBCH 3200 | 3200 | 1850 | 760 | 1350 | 2450 | 800 | 240÷1000 | 500 | 2500 | |
25 TBCH 3600 | 3600 | 2000 | 795 | 1350 | 2450 | 800 | 240÷1000 | 500 | 2500 | |
20 TBCH 4000 | 4000 | 2150 | 840 | 1350 | 2450 | 800 | 240÷1000 | 500 | 2500 | |
25 TBCH 4500 | 4500 | 2300 | 890 | 1350 | 2450 | 800 | 240÷1000 | 500 | 2500 | |
25 TBCH 5200 | 5200 | 2550 | 985 | 1350 | 2450 | 800 | 240÷1000 | 500 | 2500 | |
25 TBCH 6000 | 6000 | 2800 | 1185 | 1350 | 2450 | 800 | 240÷1000 | 500 | 2500 |
C | Lifting height |
H | Overall dimensions |
P | Weight |
B | Minimum opening |
A | Maximum opening |
L | Forklift width |
E | Forks width |
D | Load centre |
Q | Load capacity |
[
